Specification AE222(G)

AE222(G)

CPU
OS
Chipset
Memory
Graphics
Panel Resolution
Touch Panel
HDD
Optical Drive
Audio
Wireless LAN
Bluetooth
USB 3.0 port
USB 2.0 port
Card Reader
Webcam
TV Tuner
Expansion Slot
HDMI out
COM Port
Mic-in/Headphone-out
Keyboard / Mouse
AC Adapter
AIO Wall Mount Kit II
Dimension(WxDxH)
AIO Wall Mount Kit III
Net Weight
Gross Weight

Intel Core i3-4130 Processor, 3.4GHz / 3MB Cache

Windows 10 Home

Chipset

Intel® HM81 Chipset

Memory

4GB DDR3 1333 / DDR3 SO-DIMM * 2 slot / Max. to 16GB

Graphics

Intel HD Graphic 4400 / Support Intel Dynamic Video Memory Technology (AE222)
NVIDIA GeForce GT740M 2GB SDDR3 (AE222G)

Panel Resolution

21.5” LCD Panel LED Backlight (1920 x 1080 ) / Multi-touch / MSI Anti-Flicker & Less Blue Light

Touch Panel

Non Touch (For Win 8.1/Win 7) / Multi Touch (For Win 7 only)

1TB 3.5” HDD SATAIII

Optical Drive

Tray-in DVD Super Multi

Audio

2 x 3W Speakers with Sound Blaster™ Cinema

Wireless LAN

802.11 b/g/n WiFi

Bluetooth

Optional

USB 3.0 port

2 (1 with Super Charger)

USB 2.0 port

Card Reader

3 in 1 (SD, MMC, MS)

Webcam

1.0M-pixel HD

TV Tuner

Optional

Expansion Slot

Mini PCI-E x 2 (1xWiFi)

HDMI out

COM Port

Mic-in/Headphone-out

1 /1

Keyboard / Mouse

Wireless Keyboard / Mouse

AC Adapter

120W (AE222) / 150W (AE222G)

AIO Wall Mount Kit II

Y (Option)

Dimension(WxDxH)

561.7mm x 410.8mm x 93.4mm

AIO Wall Mount Kit III

Y (Option)

Net Weight

9.71 kg

Gross Weight

11.21 kg

Revolutionary 4rd-generation Intel® Core™ processors

The AE222 are powered by 4rd Generation Intel® Core™ Haswell processors manufactured with the latest 22 nm process. These new processors effectively enhance performance with reduced power consumption, and their graphics processing units are integrated into the CPUs on the same chips, which provides higher graphics capabilities, smoother high-definition video playback, as well as greater gaming experiences.

MSI Exclusive Anti-Flicker

The Flicker-free technology integrated into the AE222 display stabilizes the power current and prevents flickering invisible to the naked eye under normal conditions. When used for extended periods of time, it effectively reduces eyestrain while also improving productivity. According to medical research, the average flickering rate of conventional monitors is 200 times/sec. This means that your eyes will suffer from over 5 million flicker times in a standard 8 hour working day, which can result in computer vision syndrome.

Less Blue Light

Blue light is light with wavelengths in the 381nm to 500nm range. This can be dangerous to the human eye, causing cataract and retinal degeneration. The anti-flicker display of the MSI AE222 All-in-One PC effectively reduces blue light.

Reward your ears with Sound Blaster Cinema

The MSI AE222 is equipped with Creative Sound Blaster Cinema sound technology, which optimizes voice and surround sound effects for different scenarios and enables users to enjoy more immersive effects when watching movies or listening to music.

Sound Blaster™ Cinema is designed to bring the same great audio experience found in live performances, films, and recording studios - to the PC. Powered by the SBX Pro Studio technologies, the Sound Blaster Cinema delivers a much more realistic and immersive experience.

MSI Instant Display Technology

The AE222 is equipped with an HDMI™ (High-Definition Multimedia Interface) port which allows the units to be connected to a second monitor. They support dual-screen display and can also output the screen to a larger display device, such as a projector or a large-screen LCD TV, making the AE222 more versatile and more efficient. For signal input, the exclusively developed MSI Instant Display Technology allows the screen to enter the “standby” mode when the All-in-One PC is turned on without the need to press the power button on the unit. The screen will be turned on immediately when a device is connected to the HDMI™ input port and if the AIO PC is also powered on, you can switch to the PC via the screen power button on the side panel. This technology saves even more power on the system.

USB 3.0 with MSI Super Charger

With MSI Super Charger technology, it does not only function as normal USB 3.0 port, but also enable users to charge cell phones or MP3 players even when the system is tuned off.

The USB 3.0 supports transfer rates up to 5 Gbps, or ten times that of USB 2.0, making it the fastest transfer interface available on the market today.
